| Datasheet | R5KL1-M | R6KL1-M |
| DC Input | ||
| Max. Input Power | 7000W | |
| Start-up Voltage | 125V | |
| Max. PV Voltage | 500V | |
| PV Voltage Range | 125V-500V | |
| MPPT Range/Nominal | 125V-500V /360V | |
| Max. Input Current | 14A/14A | |
| MPPT Tracker/Strings | 2/1 | |
| AC Output | ||
| Rated Power W/VA | 5000VA/5000W | 6000VA/6000W |
| Max. Output Current | 21.7A | 26A |
| Nominal Voltage/Range | 230Vac /176Vac~270Vac | |
| Frequency | 50 /60Hz | |
| PF | 1(0.8lagging-0.8leading) | |
| THDI | < 3% | |
| AC Output Topology | L+N+PE | |
| Battery | ||
| Battery Voltage Range | 42~59V | |
| Max. Charging Voltage | 58V | |
| Charge/Discharge Current | 95A/110A | |
| Battery Type | lithium /Lead-acid | |
| Communication Interface | CAN/RS485 | |
| EPS Output | ||
| Rated Power W/VA | 5000VA/5000W | 6000VA/6000W |
| Rated Voltage | 230Vac | |
| Rated Current | 21.7A | 26A |
| Rated Frequency | 50/60Hz | |
| Automatic Switchover Time | < 20ms | |
| THDU | < 3% | |
| Parallel Operation | Yes | |
| General Data | ||
| Battery Charge/Discharge | 95% | |
| DC Max. Efficiency | 97.6% | |
| Euro Efficiency | 97% | |
| MPPT Efficiency | 99.9% | |
| Protection class | IP65 | |
| Noise Emission (Typical) | < 35dB | |
| Operation Temperature | -25～+60℃ | |
| Cooling | Natural | |
| Relative Humidity | 0 ~95% (non-condensing) | |
| Altitude | 2000m | |
| Dimensions (W/D/H) mm | 580/440/176mm | |
| Weight | 25kg | |
| Inverter Topology | Transformerless | |
| Self-Consumption | < 3W | |
| Features | ||
| Display | LCD | |
| Interface: RS485/Wi-Fi/LAN /CAN/DRM | Yes /Opt/Opt /Yes/Yes | |
| Certificates | CE, CGC, TUV, SAA, G99 | |
