| Rated output voltage | RF4830S60-H | RF4850S80-H |
| Line mode |
| AC input voltage | 220/230V AC |
| AC input voltage range | (170Vac~280Vac) ±2%；(90Vac-280Vac)±2% |
| Rated frequency | 50HZ/ 60Hz ( auto detection) |
| Frequency range | 47±0.3Hz ~ 55±0.3Hz for 50Hz; ( 57±0.3Hz ~ 65±0.3Hz for 60Hz) |
| Over-load/short-circuit protection | Circuit breaker |
| Efficiency | >95% |
| Transfer time | (AC to DC or DC to AC)： 10ms ( typical ) |
| Bypass relay current | 30A | 40A |
| Invert mode |
| Output voltage waveform | Sine wave |
| Rated output power | 3000VA/3000W | 5000VA/5000W |
| Power factor | 1 |
| Rated output voltage | 220/230（±5%）Vac |
| Rated output frequency | 50Hz ±0.3Hz/60Hz ± 0.3Hz |
| Efficiency | >92% |
| Over-load protection | 102%< Load< 125%) ±10%: fault（shutdown output）after 5 min; (125%150% ±10%: fault（shutdown output）after 50S |
| Peak power (10s) | 6000VA | 10000VA |
| Capable of starting electric motor | 2HP | 4HP |
| Output short-circuit protection | Circuit breaker |
| Output breaker current | 30A | 40A |
| DC input voltage/ Min. DC start voltage | 48VDC (minimum starting voltage 44V) |
| Battery voltage range | 40VDC~60Vdc ± 0.6Vdc |
| Power saving mode | Load≤25w |
| Charge(line) |
| Battery type | lead acid or lithium battery |
| Charge current | 60A |
| Charge current regulation | ± 5Adc |
| Battery voltage range | 40-58Vdc |
| Charge short-circuit protection | circuit breaker and blown fuse |
| Breaker current | 40A |
| Over charge protection | alarm and turn off charging after 1minute |
| Charge(solar) |
| MPPT voltage range | 60-115Vdc |
| Max. PV input voltage | 145Vdc |
| Max. PV open circuit voltage | 145Vdc |
| Battery voltage range | 40V-60Vdc |
| Max. output power | 3200W | 4200W |
| PV charging current range | 0-60A | 0-80A |
| Battery short-circuit protection | Blown Fuse |
| Wiring protection | Anti-reverse connecting protection |
| Others |
| Dimension (L*W*D) | 430X338X126mm |
| Weight | 10kg |
| Degree of protection | IP20（force air，variable speed fan） |
| Operation temperature range | -15~ 40ºC (-25ºC ～ 60ºC for storage ) |
| Relative humidity | 5%~95% |
| Communication interface | RS-485/GPRS/WiFi |
| Safe certificate/ EMC certificates | CE(EN62040-1, EN62040-2）/ C2 |
Communications base station
Nomadic area
Farm
