Model | RESS0500-1832 |
DC Parameters | |
Battery Capacity | 1.832MWH |
Number of Battery Racks | 8 |
BMS Communication Interface | RS485/CAN |
DC Voltage Range | 560V-817.6V |
AC Side Parameters | |
Rated AC Power | 500KW |
Max. AC Power | 550KW |
Rated Current | 722A |
Max. Output Current | 800A |
DC Current Component | < 0.5 % |
THDI | < 3 % |
Rated Voltage | 400V |
Voltage Range | 320V-460V |
Rated Frequency | 50/60Hz |
Frequency Range | 45-55/55-65Hz |
PF | 1lagging-1leading |
Transformer | No |
General Information | |
Protection Degree | IP54 |
Fire Fighting System | Yes |
Running Time (Full Power) | 3h |
Operation Temperature | -30~+55℃ |
Dimension(W/D/H) | 12192 ×2438×2896mm |
Weight | 35000kg |
PCS Communication Mode | RS485, CAN, TCP/IP |
PCS Communication Protocol | Modbus RTU, Modbus TCP, IEC104 |
PCS Unit Cooling Mode | Forced air |
Battery Unit Cooling Mode | Air conditioning cooling |
Maximum Altitude | 4500 m (derated above 3000m) |
Relative Humidity | 0-95% non-condensing |
