Villa
Communications base station
Farm
Household
| Datasheet | enBank 7.2K | enBank 14.4K |
| Capacity Range | 7.2KWh | 14.4KWh |
| Usable Capacity Range | 5.76KWh | 11.52KWh |
| Nominal Voltage | 48.0V | 48.0V |
| Depth of Discharge (DoD) | 80% | 80% |
| Cycle Life (80%DOD) | >6000, 25℃ | >6000, 25℃ |
| Design Life | More than 10 years (25 ℃ 77⁰F) | More than 10 years (25 ℃ 77⁰F) |
| Discharge Voltage | 45V - 54.0V | 45V - 54.0V |
| Charging Voltage | 52.5V - 54.0V | 52.5V - 54.0V |
| Max. Charging Current | 75A | 120A |
| Max. Discharge Current | 120A | 120A |
| Communication Interface | CAN+RS485 | CAN+RS485 |
| Environmental Temperature | -10℃ ~+60℃ | -10℃ ~+60℃ |
| Maximum Altitude | < 4000m | < 4000m |
| Relative Humidity | 10%~90% | 10%~90% |
| Installation Mode | Cabinet | Cabinet |
| Protection Degree | IP21 | IP21 |
| Working Temperature | -10℃~+50℃ (discharge) 0℃~+50℃ (charging ) | -10℃~+50℃ (discharge) 0℃~+50℃ (charging ) |
| Weight | 83kg | 163kg |
| Dimension (W/D/H) | 520*350*680mm | 520*350*1200mm |
| Certificates | CE | CE |
